Enphase IQ Cable Single Connection, 12 AWG, 2.3 m (7.5 ft) Connector Spacing – Q-12-20-200
SKUQ-12-20-200
The Enphase Q-12-20-200 is a connectorized IQ Cable model. Per the Americas IQ Cable accessories datasheet, it is 12 AWG with a maximum nominal voltage of 277 VAC and 2.3 m (7.5 ft) connector spacing.
Couldn't load pickup availability
Need it anyway? Request a written quote. No payment is taken.
Delivery
Shipping weight 0.81 lb. Shipping, including freight for large items, is calculated at checkout before you pay.
Need help choosing or installing?
Get one hour of personalized help with equipment selection, system questions, commissioning, or troubleshooting. Purchase your session, then use the scheduling link provided after checkout to choose an appointment.
- Trusted since 1999
- Ships from US warehouses
- 4.8 stars · 681 Google reviews
Product Overview
The Enphase Q-12-20-200 is a connectorized IQ Cable model. Per the Americas IQ Cable accessories datasheet, it is 12 AWG with a maximum nominal voltage of 277 VAC and 2.3 m (7.5 ft) connector spacing.
Choose connector spacing from the module dimensions and layout (portrait or landscape) on your plans. The Enphase datasheet lists spacing, not module orientation.
Best For
- Enphase IQ Cable trunks that need 7.5 ft connector spacing: Match spacing to the module layout before ordering.
- Two-wire IQ Cable AC trunks: Where Enphase IQ Series equipment plugs into pre-installed connectors along the cable.
Key Features & Specifications
| Specification | Details |
|---|---|
| Model number | Q-12-20-200 |
| Connector spacing | 2.3 m (7.5 ft) |
| Product type | Connectorized Enphase IQ Cable (two-wire AC trunk for Enphase IQ Series equipment) |
| Conductor size | 12 AWG |
| Maximum nominal voltage | 277 VAC |
| Certification | UL 3003 (raw cable), UL 9703 (cable assemblies), DG cable |
| Conductor type | THHN/THWN-2 dry/wet |
| Flame test rating | FT4 |
| Compliance | RoHS, OIL RES I, CE, UV Resistant, combined UL for Canada and United States |
| Source | Enphase IQ Cable accessories datasheet DSH-00247-1.0 (July 2024; Region: America) |
What You May Also Need
Usually required
- IQ Sealing Caps (Q-SEAL-10): Enphase states one is needed to cover each unused connector on the cabling (Enphase datasheet DSH-00247-1.0).
- IQ Terminator (Q-TERM-10): Enphase lists this as the terminator for unused cable ends (Enphase datasheet DSH-00247-1.0).
May be required
- IQ Disconnect Tool (Q-DISC-10): Enphase plans at least one per installation for IQ Cable connectors, DC connectors, and AC module mount (Enphase datasheet DSH-00247-1.0).
- IQ Cable Clips (Q-CLIP-100): Enphase lists these to fasten cabling to racking or secure looped cabling (Enphase datasheet DSH-00247-1.0).
Optional upgrades
- Heyco cordgrip for Enphase Q Cable (M3234GDA-SM): Liquid-tight entry into an enclosure where the Q Cable leaves the array (Heyco Enphase Q Cable cordgrip datasheet).
Check current manufacturer documentation before combining components, especially batteries, inverters, communications equipment and system-control hardware.
Important Considerations
- Match Q-12-20-200 connector spacing to the module layout before ordering.
- Do not mix connector-spacing assumptions across Q-12-10-240, Q-12-17-240 and Q-12-20-200.
- Seal unused connectors with Q-SEAL; terminate cut ends with Q-TERM.
- Ampacity is not stated on the Americas DSH-00247-1.0 datasheet used here; size branches per current Enphase electrical rules and local code.
