S-5! CorruBracket 100T Top-Fixed Bracket for 7/8" and 3/4" Corrugated Metal Roofs
SKUCorruBracket 100T
The S-5! CorruBracket 100T is a top-fixed bracket for exposed-fastened corrugated metal roofing. It mounts on the crest of the corrugation, straddling the valley, so the fasteners stay out of the drainage plane.
Couldn't load pickup availability
Need it anyway? Request a written quote. No payment is taken.
Delivery
Shipping weight 1.5 lb. Shipping, including freight for large items, is calculated at checkout before you pay.
Need help choosing or installing?
Get one hour of personalized help with equipment selection, system questions, commissioning, or troubleshooting. Purchase your session, then use the scheduling link provided after checkout to choose an appointment.
- Trusted since 1999
- Ships from US warehouses
- 4.8 stars · 681 Google reviews
Product Overview
The S-5! CorruBracket 100T is a top-fixed bracket for exposed-fastened corrugated metal roofing. It mounts on the crest of the corrugation, straddling the valley, so the fasteners stay out of the drainage plane.
S-5! says the 100T fits U.S. corrugated profiles 7/8" and 3/4" high with about 2.67" rib pitch. It can fasten into the sheeting only, or through the sheeting into the deck or purlins for heavier loads.
A slotted top hole takes a standard M8 bolt with the included M8 hex flange nut, which slides into the top groove. An EPDM gasket on the base seals against the panel.
Best For
- 7/8" and 3/4" U.S. corrugated metal roofs: S-5!'s stated profile range.
- Rail-based PV, the S-5-PV Kit, walkways and utilities: S-5!'s listed applications for the 100T.
- Roofs where structure is hard to hit: S-5! allows sheeting-only attachment anywhere along the corrugation for medium-duty use.
Key Features & Specifications
| Specification | Details |
|---|---|
| Product type | Top-fixed bracket for exposed-fastened corrugated metal roofing |
| Roof profiles (per S-5!) | U.S. corrugated, 7/8" or 3/4" high, rib pitch about 2.67" (68 mm) |
| Mounting (per S-5!) | On the crest of the corrugation; into the sheeting only, or through the sheeting into decking, purlins or trusses. Use all pre-punched holes to achieve tested holding strength. |
| Seal (per S-5!) | EPDM rubber gasket on the base; S-5! says not to remove it |
| Attachment point | Slotted top through-hole for a standard M8 bolt, with the included M8-1.25 hex flange nut in the top groove |
| Included (per S-5! installation instructions) | M8-1.25 hex flange nut. For the standard M8 bolt, check what ships with your order. |
| Material (per S-5!) | Structural aluminum |
| System listing | IronRidge's XR Flush Mount manual does not list CorruBracket 100T among its tested or evaluated third-party roof attachments (IronRidge XR Flush Mount Installation Manual, Version 5.2 (2026), p. 5). |
| Source | S-5! CorruBracket 100T and Mini Installation Instructions CB100TI-V1.1-0820; S-5! CorruBracket 100T (and Mini) brochure Version 052115; S-5! product page s-5.com/products/corrubracket-100t/, retrieved Oct. 8, 2026 |
What You May Also Need
Usually required
- An M8 bolt and your rail or mounting hardware: S-5! lists the M8 hex flange nut as included; for the standard M8 bolt, check what ships with your order. Also check whether your rail maker lists the 100T as an approved attachment.
- Screws for structure attachment, if used: S-5! lists metal-to-metal and metal-to-wood screws that are not provided.
May be required
- Sheeting screws: Check what ships with your order. S-5!'s installation instructions and product page list self-piercing screws as included, but its 100T brochure says attachment fasteners are not included.
- Bulb-type rivets: S-5! allows riveting through the pre-punched holes instead of screws. It also says to replace a stripped screw with a bulb rivet or larger fastener.
- Rail system components: See metal roof mounts.
Optional upgrades
- S-5! CorruBracket: The bottom-fixed version that fastens into structure in the low of the corrugation. See CorruBracket.
Check current manufacturer documentation before combining components, especially batteries, inverters, communications equipment and system-control hardware.
Important Considerations
- Don't over-drive fasteners. S-5! says a slight extrusion of rubber around the washer is a good visual check, and recommends a screw gun with a depth-sensing nose piece or torque clutch.
- Sheeting-only vs. structure. S-5! describes sheeting-only attachment for medium-duty applications and fixing into the deck or purlin for heavy-duty applications.
- Rail approval. IronRidge's current XR Flush Mount manual does not list CorruBracket 100T among its approved third-party attachments.
- Engineering is your responsibility. S-5! says the user or installer is responsible for all engineering and design, including spacing. S-5! publishes load test results on its website for load-critical designs.
