IronRidge QuickMount RD Structural Screw for HUG, 3" – HW-RD1430-01-M1
SKUHW-RD1430-01-M1
The IronRidge QuickMount RD Structural Screw (HW-RD1430-01-M1) fastens the IronRidge Halo UltraGrip (HUG) attachment to the roof. "RD" stands for rafter-or-deck: the same screw is used for both mounting methods.
Couldn't load pickup availability
Need it anyway? Call (877) 878-4060 for a quote.
Delivery
Shipping, including freight for large items, is calculated at checkout before you pay.
- U.S. warehouse
- Trusted since 1999
- Expert U.S. support
Product Overview
The IronRidge QuickMount RD Structural Screw (HW-RD1430-01-M1) fastens the IronRidge Halo UltraGrip (HUG) attachment to the roof. "RD" stands for rafter-or-deck: the same screw is used for both mounting methods.
Each screw is a #14 self-drilling, wood-tip stainless steel screw, 3.00" long, with a 5/16" hex head and an EPDM-backed sealing washer. IronRidge says the screw anchors HUG to the roof with the EPDM washer completing its stack of waterproofing barriers.
Best For
- Installing IronRidge HUG attachments: IronRidge says HUG is only approved for installation with IronRidge RD Structural Screws. See HUG, mill and HUG, black.
- Rafter or deck mounting: Two screws per HUG into a rafter, or six per HUG into the roof deck, per IronRidge's HUG manual.
Key Features & Specifications
| Specification | Details |
|---|---|
| Product type | Structural screw with sealing washer for IronRidge QuickMount Halo UltraGrip (HUG) |
| Part number | HW-RD1430-01-M1 (RD Structural Screw) |
| Included (per IronRidge cut sheet) | 1 self-drilling screw, #14, wood tip; 1 EPDM-backed washer |
| Screw | #14 diameter; 3.00" long; 5/16" hex head; 300 series stainless steel, clear |
| Washer | EPDM backed; 300 series stainless steel, clear |
| Used with (per IronRidge) | IronRidge QuickMount Halo UltraGrip (QM-HUG-01-M1 / -B1); the HUG cut sheet calls out this part number |
| Quantity per HUG (per IronRidge) | Rafter-attached: 2 (a 3rd if one misses the rafter). Deck-attached: 6. |
| Source | IronRidge QuickMount RD Structural Screw Cut Sheet QM-HW-RD-1430-01-M1 Rev 1.2; IronRidge QuickMount Halo UltraGrip Cut Sheet (QM-HUG-01-B1 or QM-HUG-01-M1) Rev 1.10; IronRidge QuickMount Halo UltraGrip Installation Manual Version 1.11 (2026); IronRidge XR Flush Mount Installation Manual, Version 5.2 (2026) |
What You May Also Need
Usually required
- IronRidge HUG attachments: This screw has no other listed use in IronRidge's documents. See HUG, mill or HUG, black.
- A 5/16" hex socket: IronRidge lists a 5/16" hex socket with adapter, or a 5/16" × 4" power nut setter.
May be required
- Extra screws: Order spares for rafters you miss. IronRidge says screws that miss stay in place, and a deck-attached HUG needs six.
Optional upgrades
- Approved roofing sealant: IronRidge says to cover the heads of stripped screws with an approved sealant. Its HUG manual lists compatible sealants.
Check current manufacturer documentation before combining components, especially batteries, inverters, communications equipment and system-control hardware.
Important Considerations
- Drive until the washer is compressed. IronRidge says to check that each EPDM washer is fully compressed.
- No pilot holes. IronRidge says HUG with the RD Structural Screw needs no pilot holes.
- Stripped screws on a deck mount. If three or more strip, IronRidge says to leave the HUG installed and add another attachment within the allowed spacing.
- Engineering and permits. Attachment spacing, rafter or deck requirements and load capacity are project-specific. Use IronRidge's design tools and stamped certification letters, and install under local building codes.
