Ground Mounts for Solar Panels

IronRidge Ground Mount Image
The IronRidge Ground Mount System supports a wide adjustment of tilt angle, foundation size/soil conditions, and module size. These variables can be quickly optimized for cost and performance starting with the IronRidge Design Assistant Tool.  Simply walk through the 5 easy steps below to order materials for your Ground Mount project - easy!

1) Click on the IronRidge Design Assistant Tool for Ground Mounts.

2) Choose your XR 1000 Rail:


XR1000 Rail XR Rail Thumbnail Image
Select Clear:  11', 14', 17'

  • Heavyweight mounting rail for ground mounts
  • Up to 12' spanning capability
  • Extreme load capability

3) Choose the appropriate Clamps & Grounding:

Midclamps Midclamp Thumbnail Image
Select: Clear , Black

  • Universal Fastening Object UFO
  • Bonds the modules to the rails

Endclamps Endclamp Thumbnail Image
Shop: Stopper Sleeves & CAMO

  • Stoppers snap onto a UFO
  • Turns into a bonded endclamp
  • Sized to module frame width
  • NEW- CAMO Universal Endclamp fits all modules


Grounding Grounding Thumbnail Image
Shop: Lugs & Straps

  • Only one grounding lug per row
  • Microinverter bonding kit
  • Grounding strap, rows over 50ft

4) Source locally the 2" or 3" Schedule 40 Steel Pipe, and choose the appropriate Top Caps and Rail Connectors:


Top Cap Ground Mount Top Cap Thumbnail Image
Select: 2" Top Cap, 3" Top Cap

  • Heavy duty cast steel
  • Secures quickly and easily to Schedule 40 Pipe
  • Connects vertical and cross pipes



Rail Connector Rail Connector Thumbnail Image
Select: 2" Rail Connector, 3" Rail Connector

  • Bonded connectors with hardware
  • 2 connectors per rail, secures and bonds the rail to the pipe

5) Need extra support?  Choose the appropriate Brace Assembly Kit:

Brace Assembly Ground Mount Brace Kit Thumbnail Image
Select: 2" Brace Kits, 3" Brace Kits

  • 2 pipe sleeves, diagonal brace, hardware
  • Only needed for installations requiring add'l support

Product Name  Price
  IronRidge SGA 2     IronRidge SGA 2" (7.5') Brace Assembly Kit   IronRidge 70-0200-CBR TWOCBR700200 IronRidge SGA 2" (7.5') Brace Assembly Kit $118.18
  IronRidge SGA 2     IronRidge SGA 2" (9') Brace Assmbly for 5 Panels   IronRidge 70-0205-CBR TWOCBR700205 IronRidge SGA 2" (9') Brace Assmbly for 5 Panels $140.00
  IronRidge SGA 3     IronRidge SGA 3" (7.5') Brace Assembly Kit   IronRidge 70-0300-CBR TWOCBR700300 IronRidge SGA 3" (7.5') Brace Assembly Kit $135.00
  IronRidge SGA 3     IronRidge SGA 3" (9') Brace Assmbly for 5 Panels   IronRidge 70-0305-CBR TWOCBR700305 IronRidge SGA 3" (9') Brace Assmbly for 5 Panels $185.00
  IronRidge SGA Top Cap for 2     IronRidge SGA Top Cap for 2" Pipe   IronRidge 70-0200-SGA TWOSGA700200 IronRidge SGA Top Cap for 2" Pipe $34.84
  IronRidge SGA Top Cap for 3     IronRidge SGA Top Cap for 3" Pipe   IronRidge 70-0300-SGA TWOSGA700300 IronRidge SGA Top Cap for 3" Pipe $44.44
  IronRidge U-Bolt for SGA 3     IronRidge U-Bolt for SGA 3" Top Cap   IronRidge 29-0300-HDW TWOSGAUBOLT IronRidge U-Bolt for SGA 3" Top Cap $2.96
  IronRidge XR Ground Mount Bonded Rail Connector, 2     IronRidge XR Ground Mount Bonded Rail Connector, 2"   IronRidge GM-BRC-002 TWOGMBRC002 IronRidge XR Ground Mount Bonded Rail Connector, 2" $11.75
  IronRidge XR Ground Mount Bonded Rail Connector, 3     IronRidge XR Ground Mount Bonded Rail Connector, 3"   IronRidge GM-BRC-003 TWOGMBRC003 IronRidge XR Ground Mount Bonded Rail Connector, 3" $11.75

See our Video with IronRidge as we cover the basics of their SGA ground mount solution.
